Features:
10 imported high-power superlattice array of infrared lights, IR distance 150M(Max)
Infrared auto-dimming technology,Low-carbon environmental protection and energy saving of 50%, the infrared lamp life up to 3x
Unique cooling technology,Cooling effect is good, high reliability, dustproof and waterproof
Park, set the ball machine idle for some time, automatically call preset, scan, cruise mode, the path functions
Support OSD menu
256 Preset points
8 Patrols, each patrol up to 32 presets
4 Patterns,500 commands(about 30 minute)/pattern
Auto scanning:8
PELCO_P, PELCO_D and other control protocols automatic identification
Horizontal rotation range: 360 degree, Vertical rotation range :180
Horizontal speed:0.01--350 degree/S;Vertical speed:0.01--120 degree/S
H.264/MJEG is optional, dual streaming,high compression ratio,and high quality.
Support Micro SDHC storage; SD2.0 standard
Title, date and time, stream information, azimuth angle, zoom display
Support:TCP/IP,UDP,RTSP,HTTP,DDNS,FTP,NTP,PPPOE,SMTP
Support ONVIF protocol
Built-in Web server enables the use of a standard Web browser for viewing and management.
IP66 rating
Lightning protection design, 3000V surge protection,support ONVIF
Specification:
| Models |
PT-P218MR |
| Sensor |
1/4"SONY Exview HAD CCD |
| Network chip |
Realtek 10/100M BASE-TX Self-adapting |
| Effective Pixels |
1280(H)*960(V) |
| lens |
18X optical |
| Min.Illumination |
0.7Lux(Color)@F1.6;0.01Lux(B/W)@F1.6 |
| Focal Length |
f=4.1mm(W)--73.8mm(T) |
| Iris |
F1.6--F2.8 |
| Horizontal Angle of View |
55.2 degree(W)--3.2 degree(T) |
| S/N |
>=50db(AGC OFF,Weight On) |
| IR Distance |
150m(MAX) |
| Day/night |
Auto swith |
| Parameters adjustment |
AWB,AGC,BLC |
| Electronic Shutter |
1/25--1/100000sec,Slow shutter:1/2,1/4,1/8,1/12sec |
| Audio Talkback |
1 channel MIC input,3.5 mm connector |
| Audio Output |
1 channel output,3.5 mm connector |
| Network Interface |
10/100M BASE-TX,RJ-45 connector |
| Alarm(Optional) |
Input: 7; Output: 2 |
| Video Compression |
H.264 Main Profile;
MJPEG/JPEG Baseline |
| Resolution |
1280*960,1-16.7(20)fps/sec 1280*720,1-25(30)fps/sec |
| 640*480,1-25fps/sec 320*240,1-25fps/sec 160*112,1-25fps/sec |
| Video Bitrate |
32Kbps--16Mbps,Supports CBR/VBR |
| Information Display |
Dome title,Preset title,Auto scanning title,Area scanning title,zoom,PTZ ,Alarm information,Date/Time |
| Audio Compression |
G.711, G.726,support 32 K stereo |
| Data storage |
Video and Image |
| Recording |
Manual |
| Alarm Output |
E-mail, Explorer, Software |
| Network protocol |
TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,
DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP |
| ONVIF protocol |
Support |
| Remote View |
Computer:IE 6.0 or up, max 16 user |
| Mobile Phone:Support Windows Mobile,Symbian,iPhone,Android platform |
| Horizontal range |
360 degree |
| Horizontalspeed |
0.01 degree to 350 degree/S |
| OSD |
Support |
| Vertical range |
-5 to 90 degree( Auto flip) |
| Vertical speed |
0.01 degree to 120 degree/S |
| Preset positions |
256 |
| Patrol |
8 Patrols, each patrol up to 32 presets |
| Auto scanning |
8 |
| Pattern |
4 Patterns,500 commands(about 30 minute)/pattern |
| Privacy zone |
8 area |
| International protection |
IP66 standard |
| Material |
All Aluminum crust and sphere |
| Temperature |
-35 to +55 degree |
| Working Humidity |
10 to 90% |
| Power Input |
DC12V |
| Power Consumption |
50W |
| Weight |
3.9KG |
| Dimension |
228*290(H)mm |
|
